Designed For Heat, Built To Last.
Made for large spaces and cold winters. The 40,000+ BTU Dawn 40i has an exclusive heat exchanger delivering 82% efficiency, giving homeowners the comfort they want and dealers with a product that truly performs. Available in IPI and Standing Pilot, the Dawn 40i has a full lineup of surrounds and front styles to fit seamlessly into most homes.
Fuel: Natural Gas (NG) or Propane (LP)
BTU High Input: (NG) 40,000 | (LP) 41,000
BTU Low Input: (NG) 22,000 | (LP) 20,000
Steady State Efficiency %: (NG) 80.3 | (LP) 82
P4 Efficiency %:
(NG) IPI: 70 | SP: 68.3 (LP) IPI: 72.6 | SP: 71
Valve System: Intermittent Pilot Ignition (IPI) or Standing Pilot (SP)
Propane Conversion Kit:
IPI (Optional) | SP (Included)
7 Day Shut-Off:
IPI (Standard) | SP (Available)
Heating Area: Up To 2,000 sq. ft.
Viewing Area (WxH): 28.5” x 15.4” (439 sq. in.)
Anti-Reflective Glass: Standard
Invisimesh Screen Barrier: Standard
Ceramic Oak Log Set: Standard
Ceramic Burner: Standard
Tuscan Tan Brick Panel Set: Standard
ProFlame II Remote / Thermostat:
IPI (Standard)
Remote, Thermostat, Wall Switch:
SP (Optional)
174 CFM Variable Speed Blower: Standard
Venting: 4” Exhaust / 3" Intake Co-Linear
Overall Size (WxDxH): 35.5” x 18.625” x 24”
Standard Weight: 250 lbs (113.4 kg)
Safety Tested: Yes
Warranty: DS Decade
Made In Lancaster County, PA
