Comfort Throughout Your Space
This hydronic system requires no electricity to heat water for floor heating, baseboard, freestanding radiators, heat pumps, or domestic water. They work well with new or existing oil or electric boilers. Our boilers circulate water in the front to prevent cracking. Each unit is pressure tested to 120 PSI and has a powerful heat exchanger for maximum efficiency. Constructed from 1/4” steel, the Aqua-Gem boilers easily maintain water temperature and feature a large capacity ash pan. All of our boilers are designed with a superior cast iron grate system and built to last.
Fuel: Anthracite
Heating Area:
(1100) 1,000- 2,400 sq. ft.
(3200) 2,000 - 3,500 sq. ft.
(4200) 3,000 - 5,000 sq. ft.
BTU:
(1100) 100,000
(3200) 160,000
(4200) 230,000
Efficiency: 78%
Fire Box (WxDxH):
(1100) 16.5” x 19” x 20”
(3200) 19” x 24” x 25”
(4200) 19” x 30” 25”
Fire Box Volume:
(1100) 3.6 cu. ft.
(3200) 6.6 cu. ft.
(4200) 8.2 cu. ft.
Fire Door (WxH):
(1100) 11” x 12”
(3200) 14” x 14.5”
(4200) 14” x 14.5”
Ash Pan (WxDxH):
(1100) 15” x 18” x 6”
(3200) 15.5” x 22” x 6”
(4200) 15.5” x 28” x 6”
Ash Door (WxH): 16.5” x 9”
Top Exhaust:
(1100) 6”
(3200) 7”
(4200) 8”
Rear Exhaust (Optional):
(1100) 6” (39” To Center)
(3200) 7” (42.5” To Center)
(4200) 8” (42.5” To Center)
Water Capacity:
(1100) 27 Gallons
(3200) 40 Gallons
(4200) 45 Gallons
Inlet / Outlet:
(1100) 4 (1.25")
(3200) 4 (2.00")
(4200) 4 (2.00")
Overall Size (WxDxH):
(1100) 23.5” x 25” x 49.5”
(3200) 26” x 30” x 53.5”
(4200) 26” x 36” x 53.5”
Weight:
(1100) 800 lbs.
(3200) 1,050 lbs.
(4200) 1,250 lbs.
U.L. Tested: Yes
Warranty:
5 Year Limited
1 Year Controls
Made In Lancaster County, PA
